Purpose

These instructions provide the procedures for updating the firmware version of your Innova tool using the OBD Tool Updater.

Still looking for an OBD2 scanner? Learn more here.

Reference Video:

Download the OBD Tool Updater for windows or for mac .
You may access the app either on your desktop or by searching for 'OBD Tool Updater' on your PC.
Double-click on the application to open.
The software will initially be displayed as 'Disconnected'.
(Note - If using a USB charging cable, and not a USB data cable, you'll get the 'Disconnected' message.)
1.Charging cables: Can only charge devices, but cannot transfer data. These are commonly called 'Charge-only' cables.
2. Data cables: Does both; charges your devices and transfers data
After installing the updater app
Connect your tool to your computer using a USB data cable - it may be a mini or micro depending on the tool. Wait a few seconds for the software to detect it.
(Note: The USB port to connect your device to your computer is at the bottom of the device.)
The tool status will now appear as 'Connected'. It will also display the Firmware, Bootloader, and Database that the tool is currently at.
If the tool is connected to the computer but the app shows a 'Disconnected' status, perform the following:
Please make sure the USB data cable to the computer and your tool are properly seated.
Try switching to a different USB port.
Try another USB cable.
Make sure you are using the right Updater. Older model tools are not compatible with the new, OBD2 Tool Updater.

Possible Issue Tool is connected to computer but app shows "Disconnected" status

Please make sure the USB to the computer and your tool are properly seated
Try switching to a different USB port
Try another USB cable
Make sure you are using the right Updater. Older tools are not compatible with our newest updaters. To make sure you're using the right one, please download the the updater that is listed by your tool. We at Innova apologize if this seems confusing. The newer updater does not support really really old tools.

Possible Issue Your tool is connected but do not see "Update my tool now" button

Possible Issue You're seeing the below issue on your Mac.

If you are on an apple device and get this issue:
- Instead of 'double clicking' on the app, please 'right click' and select Open and the app should open correctly.

Wait a few more seconds for the software to check for updates. If updates are available for your device, it will provide the option 'Update my tool now'. Select this option to begin the update process. This process may take some time.When your update is stuck at 1% (or 5%) and not progressing, perform the following:
- Uninstall the updater app from your computer.
- Reboot your computer.
- Disable any Antivirus.
- Reinstall the updater.
- Attempt the update again by following the steps in this guide.
If you have tried the above procedures but the issue remains unresolved, follow the instructions below:
- Swap out the USB cable with a new one.
- Switch USB ports.
- Switch to a different computer.
- Try updating again.
Note: If your tool is connected but you do not see an 'Update my tool now' button as shown in the image, that means your tool is already up to date to the latest version and there are no new updates for your tool.

Possible Issue: If your update is stuck at 1% (or 5%) and not progressing.

Your updater may be out of date.

While your device is updating, please make sure to keep it connected.
The update will be divided into individual steps such as bootloader, firmware, and database. This process may take up to 25 minutes. Please wait for all steps to complete.
If an error occurred during the update, the software will display the last progress percentage and the message 'Update Error'. Please connect your tool and try again'. Please disconnect and reconnect the tool to attempt the upgrade process again.

If the update finishes successfully, the software will display the message 'Update Complete'. At this point, the tool has been updated and can be disconnected. You may now exit the Updater and safely disconnect your tool from your computer. Once you re-plug your device into your vehicle, your firmware should immediately display your device's latest firmware version.
